KEAN G1005-D Gravel Frameset
R20 990.00
Size
In stock
KEAN G1005-D Gravel Frameset
Product Details
Brand: KEAN
Category: Frameset
TECHNICAL SPECIFICATIONS
| Model | G1005-D |
| Frame | 700C Full Carbon Gravel Disc Brake Bike Frames |
| Including | Frame + Fork + Seatclamp + Spacers + Headset + Stem |
| Frame Sizes | 49/52/54/56/58cm |
| Stem Sizes | 90/100/110/120mm |
| Cable Routing | Full Internal Cable Routing (HT/RB/FD/RD) |
| Cable plug | Mechanical and DI2(2 in 1) |
| Weight | 1050g (54cm/BB86), 450g (fork) |
| HeadTube | 1 1/2" – 1 1/2"（upper 52mm lower 52mm, FSA standard) |
| Seat Post | 31.6mm |
| Bottom Bracket | Pressfit BB86.5 |
| Tire Max | 700*50C |
| O.L.D | Rear TA Φ12*142mm, Fork TA Φ12*100mm |
| Disc Brake | Shimano Flat Mount 140mm or 160mm |
| Fork offset | 50mm |
| Max Chainring | 53-39T / 50-34T |
| Fender&rack mount | Yes |
| Testing standard | ISO4210 |
| Warranty | 2 years |
GEOMETRY
| SIZE | CF | L | I | A | B | F | P | T | D | R | G | STACK | REACH | WB |
| 490 | 490 | 524.9 | 149.1 | 74.5° | 70.5° | 599.6 | 435 | 120 | 67 | 50 | 395 | 537.8 | 375.9 | 1025.8 |
| 520 | 520 | 534.8 | 159.6 | 74° | 71° | 600.6 | 435 | 140 | 67 | 50 | 395 | 556.6 | 375.2 | 1026.7 |
| 540 | 540 | 545 | 174 | 73° | 71.5° | 595.4 | 435 | 150 | 67 | 50 | 395 | 568 | 371 | 1021.3 |
| 560 | 560 | 560 | 180 | 73° | 72° | 605.8 | 435 | 170 | 67 | 50 | 395 | 588.9 | 380 | 1031.8 |
| 580 | 580 | 575 | 191 | 72.5° | 72° | 615 | 435 | 190 | 67 | 50 | 395 | 605.9 | 384 | 1041.1 |
