Race Face Arc Offset Rim 29er

Please Note: We must insist you use nipple washers on all Race Face ARC rims to complete the wheel build.

Features

• Sizes from 25mm to 40mm internal width
• Tubeless ready, strong tire retention bead
• New 30mm Heavy Duty for gravity and e-bike applications

27.5 ” Tubeless ready

• Rim height 25mm – 418g, 30mm – 484g, 35mm – 520g, 40mm – 560g, 30mm Heavy Duty – 555g
• Finish brushed black anodize / vinyl decals
• Type tubeless ready clincher (tape and valve kit sold separately) rim material 6069 high strength alloy
• Rim depth 20mm, 22mm Heavy Duty
• Rim offset 4.5mm
• Internal rim width 25mm, 27mm, 30mm, 35mm, 40mm, 30mm Heavy Duty
• External rim width 29mm, 31mm, 34mm, 39mm, 44mm, 34mm Heavy Duty
• Spoke holes 32, 28, (Heavy Duty only 32)
• Rim ERD 562mm (25-40mm)
• Max spoke tension 122KGF / 1200N

29″ Tubeless ready

• Wheel size 29″
• Rim height 25mm – 445g, 30mm – 525g, 35mm – 553g, 40mm – 596g,30mm Heavy Duty – 591g
• FINISH BRUSHED BLACK ANODIZE / VINYL DECALS
• TYPE TUBELESS READY CLINCHER(tape and valve kit sold separately)
• RIM MATERIAL 6069 HIGH STRENGTH ALLOY
• RIM DEPTH 20mm, 22mm Heavy Duty
• RIM OFFSET 4.5mm
• INTERNAL RIM WIDTH 25mm, 27mm, 30mm, 35mm, 40mm, 30mm Heavy Duty
• EXTERNAL RIM WIDTH 29mm, 31mm, 34mm, 39mm, 44mm, 34mm Heavy Duty
• SPOKE HOLES 32, 28, (Heavy Duty only 32)
• RIM ERD 600mm (25-40mm)
• MAX SPOKE TENSION 122KGF
