Rapide Ultralight PRO Boost Rear Hub 32 Hole

Shimano® Micro Spline

Shimano® HG

SRAM® XDR/XDR

SunRace

The Rapidé Ultralight PRO Boost rear hub is made from precision machined AL6061-T6 alloy and spins on top quality Enduro sealed cartridge bearings. The large diameter hub flanges provide a wide bracing angle for the 32 spokes for maximum lateral stiffness.

The Rapidé Ultralight PRO Boost rear hub is compatible with 148 x 12mm thru axles. Also compatible with Boost 141 by choosing the quick release end caps option.

The light weight alloy cassette body is compatible with Shimano® type 9/10/11/12 MTB and road 9/10/11 speed cassettes and features a super quick engaging 36 point/10° four pawl ratchet for reliable power transfer under all conditions. A light weight SRAM XD Driver cassette body is also available.

Main Features

• Large hub flanges
• 32 spoke
• Equipped with Enduro sealed bearings
• 6 bolt disc mount pattern
• Quick engaging 36 point/10° four pawl cassette
• XD Driver cassette option
• Compatible with 148 x 12mm thru axles
• Compatible with Boost 141 QR
• 299g

Hub Specs

Rapidé Ultralight PRO Boost Rear Hub
OLD: 148mm
Left Flange: PCD 58mm
Right Flange: PCD 58mm
Center to left flange: 37.74mm
Center to right flange: 21.26mm
Spoke Hole: Ø2.7mm

Bearings
Hub Shell
2 x Enduro ABEC 3 6902 2RS bearings LLB seals

Shimano® HG Freehub
1 x Enduro ABEC 3 6802 2RS bearing LLB seals
1 x Enduro ABEC 3 6902 2RS bearings LLB seals

Shimano® Micro Spline Freehub
2 x Enduro ABEC 3 6802 2RS bearing LLB seals

SRAM® XD/XDR Freehub

2 x Enduro ABEC 3 6802 2RS bearing LLB seals
